P/N: 036093050
With Hei-TORQUE Expert 200 you can optimally stir viscosities up to 100,000 mPas or volumes up to 50 liters (H2O). Thanks to a wide speed range from 10 to 2,000 rpm and a maximum torque of 200 Ncm, it works particularly powerful.
The laboratory stirrer Hei-TORQUE Expert 200 performs every stirring task with minimal noise thanks to the latest engine technology. This laboratory stirrer is also very user-friendly in terms of operation and safety. The 2.4 inch display makes it very easy to set the application parameters and control the process (e.g. using the torque trend display). The safety-related start/stop touch-function serves to minimize the risk of unintentional switching on.
Suitable for use in fume hoods or as a drive for reactor superstructures, the Hei-TORQUE Expert 200 has a quick-action chuck (quick chuck with safety ring) with a diameter of 10.5 mm, which can be combined with a large number of stirring tools for the best stirring results.
200 Ncm
Performance graph of
Hei-TORQUE Expert 200
Number of speed gears | 1 |
---|---|
Rotation speed range | 10 – 2,000 rpm |
Rotation speed indicator | digital monochrom 2.4" |
Speed control | electronic |
Max. torque | 200 Ncm |
Torque indicator | symbol |
Overheat protection | automatic cut-out |
Viscosity max. | 100,000 mPa s |
Stirring cap. (H2O), max. | 50 l |
Throught-shaft design | yes |
Shaft diameter, max. | 10.5 mm |
Counter/ Timer | - |
Analog / digital interface | - |
Power rating motor input | 120 W |
Protection class IEC 60529 | IP 54 |
Heidolph Life Science Solutions | Download |
Hei-TORQUE at a glance | Download |
Configuration tool Heidolph stirring system | Download |
NRTL-Certificate-Overhead-Stirrers.pdf | Download |
Hei-TORQUE-Certificate-for-continuous-operation.pdf | Download |
Operating instructions Hei-TORQUE Expert / Ultimate | Download |
The technical data do not match exactly due to the various developments in the meantime. Nevertheless, comparable devices are staggered as follows ...
The tightening torque of the quick release chuck is individually adjustable ...
The Hei-TORQUE Expert models shows bars on the display, indicating changes in the torque or viscosity of the fluid.
The Hei-TORQUE Ultimate models show the actual torque in Ncm with one decimal place.
The numbering on the Hei-TORQUE models describes the respective torque of the overhead stirrer. For example ...
The Quick-Chuck is made of polyamide (PA) and thermally stable up to 115 ° C.
